Built with our proprietary wire-braid process technology, MegaSys™
MXG™ 4K High Pressure Hydraulic hose is lightweight, highly flexible,
and qualified to ONE MILLION impulse cycles — it’s a drop-in
replacement for conventional spiral hoses. Using materials science
advancements, design expertise and processing technologies, we
engineered a hydraulic hose that exceeds the performance of wire
spiral constructions, but with the lower weight and flexibility driven by
Gates wire-braid technology. The XtraTuff™ Plus cover on MXG™ 4K
hose offers 25X the abrasion resistance of standard covers, as well as
impressive ozone resistance.
| DETAILS | |
|---|---|
| SIZE ID (IN) | 3/8 - 1 |
| STANDARD | Two layers of braided, high-tensile steel wire |
| MATERIAL | Black, XtraTuff™ Plus abrasion resistant, ozone resistant, synthetic rubber; smooth cover |
| WORKING PRESSURE (PSI) | Max 4060 |
| TEMPERATURE RANGE | -40°C to +121°C (-40°F to +250°F) |
